| Parameter | Mux/Demux | ||
| Channel Wavelength（nm） | C/L Band, ITU Grid | ||
| Channel Spacing（GHz） | 100 | 200 | |
| Channel Passband (@-0.5dB bandwidth)(nm) | ≥0.22 | ≥0.5 | |
| Pass Channel Insertion Loss (dB) | ≤0.9 | ≤0.4 | |
| Reflection Channel Insertion Loss(dB) | ≤0.4 | ≤0.4 | |
| Isolation（dB） | Pass Channel | ≥30 | |
| Reflect Channel | ≥13 | ||
| Ripple (dB) | ≤0.3 | ||
| Wavelength Temperature Shifting (nm/℃) | ≤0.005 | ||
| Polarization Dependent Loss（dB） | ≤0.15 | ||
| Polarization Mode Dispersion（ps） | ≤0.1 | ||
| Directivity（dB） | ≥50 | ||
| Return Loss（dB） | ≥45 | ||
| Maximum Power Handling（mW） | 500 | ||
| Opterating Temperature(℃) | -40~+85 | ||
| Storage Temperature(℃) | -40~+85 | ||
| Package dimension(mm) | Φ5.5 x L34 | ||
